Waveshare LED-Display 2.9 296×128 ePaper Display Modul mit SPI Interface, dreifarbig (rot

Übersicht This is an E-Ink display module, 2.9inch, 296x128 resolution, with embedded controller, communicating via SPI interface, supports red, black, and white three-color display. Due to the advantages like ultra low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf label, industrial instrument, and so on. Eigenschaften No backlight, keeps displaying last content for a long time even when power down Ultra low power consumption, basically power is only required for refreshing SPI interface, for connecting with controller boards like Raspberry Pi/Arduino/Nucleo, etc. Comes with development resources and manual (examples for Raspberry Pi/Arduino/STM32) Spezifikationen Operating voltage: 3.3V Interface: 3-wire SPI, 4-wire SPI Outline dimension: 89.5mm × 38mm Display size: 66.89mm × 29.05mm Dot pitch: 0.138 × 0.138 Resolution: 296 × 128 Display color: black, red, white Grey level: 2 Full refresh time: 15s Refresh power: 26.4mV(typ.) Standby power: <,0.17mV Viewing angle: >,170° Interface SYMBOL DESCRIPTION VCC 3.3V GND Ground DIN SPI MOSI pin CLK SPI SCK pin CS SPI chip selection, low active DC Data/Command selection (high for data, low for command) RST External reset, low active BUSY Busy status output, low active Lieferumfang 2.9inch e-Paper Module (B) Cable XH2.54 20cm 8Pin Dokumentation / Downloads https://www.waveshare.com/wiki/2.9inch_e-Paper_Module_(B)
